Product Description:
The Bluesea SafetyHub 100 combines an ignition-protected fuse block and an integrated connecting plug. It is safe for use on gasoline-powered boats, reduces wiring connections, and consolidates up to seven fused circuits. It saves time on wiring in different fuse holders for different current ratings, as well as minimising wire routing.
- Three 30A−200A MIDI®/AMI® fuses [sold separately] ideal for high-amp circuits, including panel feeds, windlasses, and stereo amplifiers
- Four 1A−20A ATO®/ATC® fuses [sold separately], ideal for circuits including bilge pumps, alarms, and clock memory
- Sealed cover protects fuses from the harsh marine environment: IP66 rating—protected against powerful
water jets
- Integrated connector plugs eliminate loose wires and provide a secure, waterproof connection
- Ignition-protected fusing meets Coast Guard and ABYC requirements for installation on gasoline or diesel-powered boats
| Specifications |
|
|
| Number of Circuits |
|
7 |
| Stud Size |
|
M8 x 1.25 |
| Operating Voltage |
|
12, 24, 32 V |
| Amperage Maximum Operating - combined |
|
280A |
| Recommended Ring Terminal |
|
M8 (5/16") |
| Screw Torque, 8-32 |
|
18in-lb (2.03 Nm) |
| Screw Torque, M5 |
|
27in-lb (3.05 Nm) |
| Stud Torque |
|
180 in-lb (20.34 Nm) |
| Weight |
|
3.20lb (1.45 kg) |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
7725 |
