FUSE HOLDER MIDI 200A 32VDC

Product Code: BS7720

Price: €45.38 (Incl Vat)

Product Description:


  • Ignition protected for installation aboard gasoline or diesel-powered boats
  • Sealed cover protects fuses from the harsh marine environment
  • Insulating cover satisfies ABYC/USCG insulation requirements
  • Cover breakouts allow wire access in any direction
  • 200A maximum with 4/0 cable
  • Accepts Blue Sea Systems Square Format standard or custom label



Specifications
Maximum Amperage **   200A ***
Maximum Voltage   Maximum Voltage 32 VDC
Stud Size   M8 x 1.25
Fuse Screw   M5 x 0.8
Recommended Screw Torque   3.05 Nm
Recommended Stud Torque   13.56 Nm
Ring Terminal Size   M8
Weight   0.07 kg
Manufacturer   Blue Sea
Manufacturer Part Number   7720




** Maximum amperage ratings are dependent on the use of appropriately sized fuses and wire for a given application.

*** With 4/0 AWG (70 mm) cable.
