Product Description:
Single pole panel mount thermal circuit breaker with a manual trip combining circuit breaker protection with switching functionality. Suitable for DC circuits up to 48Vdc.
- Visible reset lever shows an open condition
- Ignition-protected - Safe for installation aboard gasoline-powered boats
- Meets SAE J1171 external ignition protection requirements
- Weather Resistant
- Combines switching and circuit breaker functions into one unit *
- "Trip Free" - cannot be held closed after trip
* Do not use as a switch where high inrush currents are expected.
| Amperage |
|
50 A |
| Maximum Voltage |
|
48V DC |
| Mounting |
|
Panel Mount |
| Circuit Breaker Type |
|
Thermally responsive Bi-metal blade |
| Terminal Stud Torque |
|
5.65 Nm |
| Interrupt Capacity ** |
|
3000A @ 48 V *** |
| Minimum Operating temperature |
|
-40° C |
| Maximum Operating temperature |
|
+85° C |
| Circuit Breaker Class |
|
Type III - switchable/manual reset - trip free |
| Terminal Stud |
|
M6 (accepts 1/4" Ring Terminal) |
| Weight |
|
0.23 kg |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
7083 |
** The fault current that a device, normally a fuse or circuit breaker is capable of breaking without damage.
*** Achieved using SAE J1625
