Product Description:
- Ignition protected for installation aboard gasoline or diesel-powered boats
- Sealed cover protects fuses from the harsh marine environment
- Insulating cover satisfies ABYC/USCG insulation requirements
- Cover breakouts allow wire access in any direction
- 300A maximum with 4/0 cable
- Accepts Blue Sea Systems Square Format standard or custom label
- Fuses sold separately
| Specifications |
|
|
| Maximum Amperage ** |
|
300A *** |
| Maximum Voltage |
|
32V DC |
| Stud Size |
|
M8 x 1.25 |
| Recommended Stud Torque |
|
13.56 Nm |
| Ring Terminal Size |
|
M8 (5/16") |
| Weight |
|
0.07 kg |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
7721 |
** Maximum amperage ratings are dependent on the use of appropriately sized fuses and wire for a given application.
*** With 4/0 AWG (70 mm) cable
