SD13 CABLE PLUG & IN-LINE SOCKET 7-WAY IP68
Product Code: HS8181-7W
Product Description:
| Number of Contacts |
|
7 |
| Cable Plug Contact |
|
Male |
| In-Line Socket Contacts |
|
Female |
| Mating |
|
Thread Locking |
| Current rating |
|
5A |
| Rated voltage |
|
380VAC |
| Test voltage |
|
1500VAC |
| Contact Resistance |
|
2mΩ |
| Insulation Resistance |
|
2000MΩ |
| Wire Connection |
|
Solder |
| Max. Wire Size |
|
0.5m² |
| Overall Cable dia. |
|
2.5 to 5mm |
| Environmental Rating |
|
IP68 |
| Manufacturer Part Number |
|
SD13-7W |
