PANEL INDICATOR 24V RED 7mm
Product Code: 53-XD7124VRED
Product Description:
| Indicator Type |
|
Miniature panel indicator |
| Voltage Rating |
|
24V ac / dc |
| Current Rating @ 12 V dc |
|
10 mA |
| Lamp Type |
|
LED |
| Color |
|
Red |
| Panel Cut-out |
|
7 mm |
| Suitable Panel Thickness |
|
0.5 - 6 mm |
| Bezel Diameter |
|
7.7 mm |
| Bezel Height |
|
5.5 mm |
| Depth Behind Panel |
|
30 mm |
| Terminals |
|
Wire-Ended |
| Wire Length |
|
150 mm |
| Lens / Body |
|
Plastic |
