AMMETER SHUNT 500A 50mV FOR BLUE SEA 82xx & 18xx METERS
Product Code: BS8255
Product Description:
| Specifications |
|
|
| Continuous Duty |
|
66% of Rated Current |
| Full Scale |
|
50 mV |
| Intermittent Duty |
|
300% @ 3 Seconds |
| |
|
100% @ 5 Minutes |
| Ratio |
|
500A DC / 50mV DC |
| Recommended Torque |
|
0.79 N·m Brass Fittings |
| |
|
21.47 N·m M10 Bolts |
| Shunt Type |
|
Resistive, Manganin Metal Element |
| Weight |
|
0.32 kg |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
8255 |
