RELAY PCB MOUNTING SPCO 12VDC 10A
Product Code: HR0302
Product Description:
| Nominal voltage |
|
12 VDC |
| Operating voltage |
|
9 to 13.2 VDC |
| Dropout Voltage |
|
1.2 VDC |
| Switching current |
|
10 A @ 250 VAC |
| |
|
10 A @ 30 VDC |
| Contact configuration |
|
1 Change Over (SPCO) |
| Contact material |
|
AgCdO |
| Coil resistance |
|
320 Ω |
| Coil consumption |
|
375 mW |
| Pitch |
|
2.54 mm |
| Switching voltage |
|
110 VDC / 250 VAC |
| Operate / Release Time |
|
10 / 5 ms |
| Mechanical Life |
|
1 x 10^7 |
| Electrical Life |
|
1.2 x 10^5 |
| Dimensions (L x W x H) |
|
19 x 15.5 x 15.3 mm |
| Manufacturer |
|
Songle |
| Manufacturer Part Number |
|
Manufacturer |
