Product Description:
- The fuse system recommended by most inverter manufacturers for high-speed response to short circuits
- Clear insulating cover, satisfies ABYC/USCG requirements
- For use on systems up to 160 Volts DC
- Large 5/16" stud terminals accept ring terminals for wire up to 4/0 AWG
- Large heat-dissipating tin-plated copper mounting blocks
- Two # 8 accessory terminals located on each end
| Specifications |
|
|
| Ignition Protection ** |
|
No |
| Maximum Amperage *** |
|
400 A |
| Maximum Voltage |
|
Maximum Voltage 160 VDC |
| Fuse Mounting Blocks |
|
Tin-Plated Copper |
| Maximum Cable Size |
|
4 / 0 AWG |
| Maximum Torque |
|
21.47 Nm |
| Mounting Hole |
|
1/4 Screw |
| Terminal Stud Size |
|
3/8" - 16 |
| Weight |
|
0.5 kg |
| Manufacturer |
|
Blue Sea |
| Manufacturer Part Number |
|
5502 |
** Ignition-protected devices, which operate in a potentially explosive environment, must be ignition-protected. This would include engine rooms with gasoline engines. There is a very specific set of tests that a device must pass to claim ignition protection. They include operating safely in an explosive mixture of propane and air.)
*** Maximum amperage ratings are dependent on the use of appropriately sized fuses and wire for a given application.
